BSJ300L Roots Type Vacuum Pump 1000m3/h 3.7kW Good Geometrical Symmetry

Model Number : BSJ300L

Certification : CE

Place of Origin : China

MOQ : 1 set

Supply Ability : 1000 sets per month

Delivery Time : 5-30 days

Packaging Details : wooden box

Surface : Painting

Color : Army Green

Pumping Rate : 1000 m³/h(16667L/min)

Material : Aluminium alloy

G.W. : 128kgs

N.W. : 115kgs

Meas. : 102*50*50cm

Features : Corrosion resistance

Contact Now

1200 m³/h Army Green, 3.7kW Mechanical Booster Pump, Roots Pump BSJ300L,60HZ

Description :

Roots vacuum pumps, which are also called Roots blowers, are rotary plunger-type pumps where two symmetrically shaped impellers rotate in opposite directions inside the pump housing.

Characteristics:

The use of an oil-free intermediate seal, multiple sealed ways ensures a high clean vacuum environment in the rotor chamber.
Advanced processing ensures the good geometrical symmetry of the rotors, as well as low noise and long service life.
The whole rotors are made of aluminum alloy, which has the characteristics of fast corrosion resistance and energy-efficient.

Technical Parameter :

Model		Units	BSJ300L
Pumping Rate	50 Hz	m³h^-1 / Lmin^-1	1000/16667
	60 Hz		1200/20000
Max Inlet Pressure	50Hz	Pa	1.3x10³
	60Hz	Pa	1.1x10³
Ultimate Vacuum		Pa	0.4
Motor Power		kW(hp)	3.7 (5.0)
Inlet		--	VG100
Outlet		--	VF80
Cooling Method		Water-cooled
Oil Need		L	2.0
Ambient Temp.		℃	5~40
Oil		--	BSO-46

Note: The value of 'Ultimate Pressure' in this sheet is measured by the Pirani gauge when the Baosi special pump oil is used, and the value should be 4x10^-3 if the McLeod gauge is used.

Performance Curve:

BSJ300L Roots Type Vacuum Pump 1000m3/h 3.7kW Good Geometrical Symmetry

Dimensions:

BSJ300L Roots Type Vacuum Pump 1000m3/h 3.7kW Good Geometrical Symmetry

Applications

Vacuum distillation
Vacuum packaging
Thin-film coating
Freeze drying
Electrical engineering
Printing
Surface treatment technique
Wind Energy
Ceramics and glasses

BSJ300L Roots Type Vacuum Pump 1000m3/h 3.7kW Good Geometrical Symmetry

Product Tags:

3.7kW Roots Type Vacuum Pump

BSJ300L Roots Type Vacuum Pump

1200m3/H roots type pump
